TOA HA-1060EN ลำโพงฮอร์นอาเรย์ Horn Array Speaker 60W (EN54)

Rated Input

60 W

Rated Impedance

100 V line: 170 Ω (60 W), 330 Ω (30 W) 70 V line: 83 Ω (60 W), 170 Ω (30 W)

Sensitivity

111 dB (1 W, 1 ml (500 Hz - 5 kHz, IEC60268-5)

Max. SPL

128 dB (60 W, 1 ml (500 Hz - 5 kHz, IEC60268-5)

Frequency Response

520 Hz - 4.6 kHz (-10 dB) 350 Hz - 11 kHz (-20 dB)

Speakers Component

Horn speaker unit x 8

IP code

IP66

EN 54-24 specifications

Sensitivity: 89 dB (1 W, 4 m) Max. SPL: 106 dB (60 W, 4 m) Coverage Angle (-6 dB):
Horizontal: 190 ° (500 Hz), 165 ° (1 kHz), 85 ° (2 kHz), 45 ° (4 kHz)
Vertical: 40' (500 Hz), 25 ° (1 kHz), 15 ° (2 kHz), 15 ° (4 kHz) Environmental Type: B (outdoor applications)

IP Code: IP33C

Speaker Cable

4-core cabtyre cord 2 m

Cable Gland

Size: PG 13.5 - 12 (gray) ···1

Cable Diameter Range: 12.5 - 6.5 mm (0.49" - 0.26") Size: PG 13.5 - 08 (black) ···1

Cable Diameter Range: 9 - 4.5 mm (0.35" - 0.18") Two cable glands are factory-installed.

Input Terminal

Ceramic terminal (3-pole), can be bridge-connected ···1 Ceramic terminal (2-pole) ···1

Thermal fuse is included.

Applicable Wire Size

For Ceramic terminal (3-pole)

Conductor: Solid wire or 7-core wire

No bridge connection: 0.8 - 10 mm² (AWG 18 - 7) for solid wire, 0.8 - 8 mm² (AWG 18 - 8) for 7-core wire

Bridge connection: 0.8 - 2.5 mm² (AWG 18 - 13) for solid wire, 0.8 - 1.5 mm² (AWG 18 - 15) for 7-core wire

Operating Temperature

-20°c to + 55 °c

Finish

Case: Aluminum, white (RAL 9016 equivalent), salt-resistant, paint Front grille: Aluminum, white (RAL 9016 equivalent), paint

Bolts: Stainless steel

Dimensions

167 (W) x 1233 (H) x 140.5 (D) mm (excluding projection)

Weight

14 kg (unit only)

Accessory

Terminal box

Option

Speaker mounting bracket: YS-1100A
